Bosch MAP Sensor, 1.15 bar - PSA-N

Bosch part number: F02U.V0U.197-02 (F02UV0U197-02)

Absolute air-pressure sensor (PSA-N), designed for airbox pressure measurement on gasoline and diesel engines, with a piezo-resistive element and integrated amplification and temperature compensation.

- Application range 0.1 to 1.15 bar absolute (withstands 5 bar)
- Fast response: 1.0 ms (T10/90); analog 0.5-4.7 V output, 4,041.62 mV/bar
- Accuracy ±0.016 bar full-scale in the 10-85°C compensated range
- -40 to 125°C operating and media temperature; 11-16 V supply; 21 grams
- AS-terminated (ASL606-05PC-HE); suits ROZ95/98, M15, E22 and diesel fuels
- Bosch recommends an RC low-pass (tau 0.2 ms) at the ECU input

When you need it
Naturally aspirated airbox/barometric measurement where response speed and accuracy matter, the reference for ram-air correction and altitude compensation. For boosted manifold pressures, see our MAP and T-MAP sensor range. Not sure what your programme needs? Talk to us. 909 supplies, installs, supports and calibrates the full Bosch Motorsport range.

Data sheet (PDF)
