Bosch Inertial Measurement Unit MM7.10

Bosch part number: F02U.V03.092-02 (F02UV03092-02)

Six-axis inertial measurement for vehicle dynamics: roll, pitch and yaw rate plus three-axis acceleration, on CAN.

- Roll / pitch / yaw rate: ±163°/s (over-range limit ±1,000°/s), 0.1°/s resolution
- X / Y / Z acceleration: ±4.2 g (over-range limit ±20 g), 0.01 g resolution
- Selectable cut-off frequency: 15 / 30 / 70 Hz (-3 dB)
- CAN output, 1 Mbaud or 500 kbaud, defined IDs (0x174 / 0x178 / 0x17C)
- 80 x 56 x 23.3 mm, 35 grams without wire; 8–16 V supply; -20 to 85°C
- Must not be mounted with the connector pointing upwards
- This listing is the motorsport-connector version; production-connector and open-end wire versions are available to order

When you need it
The inertia reference for serious data and control work: chassis and damper analysis, aero platform study, traction and stability strategies — and pitch rate for wheelie-sensitive launch work. It is also the yaw/acceleration sensor used by the Motorsport ABS M5 kits, so it serves as the ABS spares line. For applications where five axes are enough, the MM5.10 (yaw/roll rate & acceleration) sits below it in the range. Not sure what your programme needs? Talk to us — 909 supplies, installs, supports and calibrates the full Bosch Motorsport range.

Data sheet (PDF)
