Bosch Rear Collision avoidance Radar - CAS-M Light

Bosch part number: F02U.V02.220-01 (F02UV02220-01)

Radar-based rear collision warning in a single 199 grams sensor: integrated logic tracks the nearest approaching vehicle and reports over CAN to the display you already run.

- 150 m detection range; tracks the nearest object; 50 Hz CAN update
- 76-77 GHz FMCW radar (Bosch MRRe14HBW-based); speed and distance via Doppler
- This variant: 1 Mbaud CAN (500 kbaud variant available to order)
- 60 x 70 x 32 mm, 199 grams, IP 6K6K/6K7, -40 to 85°C, 6.5-18 V
- Needs yaw rate and vehicle speed as inputs; renders on any CAN display (e.g. DDU 10 / DDU 11)

When you need it
The same watch-your-back protection as the full CAS-M 3 in a minimal package, ideal where weight and complexity matter and a nearest-vehicle warning is enough.

Choosing a collision-avoidance system
- CAS-M 3: radar + high-definition camera + dedicated 7" display: tracks up to 40 approaching vehicles, marks up to 4 on screen with LED warnings. The full multi-class endurance solution
- CAS-M Light: radar with integrated logic and a CAN output: tracks the nearest approaching vehicle to 150 m and warns through your existing CAN display. The lightweight single-sensor option
Both are built on Bosch's MRRe14HBW radar and need vehicle speed and yaw-rate inputs. Not sure what your programme needs? Talk to us. 909 supplies, installs, supports and calibrates the full Bosch Motorsport range.

Data sheet (PDF)
